ENGINE TECHNICAL DATA
- Manufacturer KOHLER
- Model KDI 2504TM-40
- Power HP/kW 48.8/36.4
- Power according to ISO 14396 standard
- Diesel engine type 4 stroke
- Speed range rpm 1500
- Displacement liters 2,482
- Cylinders, number and configuration 4 in line
- Bore x stroke mm 88 x 102
REFRIGERATION SYSTEM
- Cooling type Liquid
- Thermostat opening temperature ºC 79-94
- Maximum coolant temperature ºC 115
- Air flow for cooling in radiator m3/h 7200
- Engine block coolant volume liters 5.2
- Coolant volume in engine+radiator liters 10
INTAKE SYSTEM
- Suction type m3/h Turbo
- Air filter type Dry
- Intake air flow rate (air 1.2 kg/m3) kg/h 177
LUBRICATION SYSTEM
- Oil change interval 500 hours
- Maximum amount of oil in sump with filter liters 11.3
- API -CH4 Oil Minimum Specifications
- Factory oil viscosity 15W40 S
FUEL SYSTEM
- Type of injection and regulation Mechanical, direct injection
- Fuel consumption at 100% continuous load litres/hour 11.09
- Fuel consumption at 75% continuous load litres/hour 8.42
- Fuel consumption at 50% continuous load litres/hour 5.79
EXHAUST SYSTEM
- Exhaust gas temperature ºC 530
- Exhaust gas flow rate kg/h 185
- Maximum restriction (back pressure) exhaust mbar 80
ELECTRIC SYSTEM
- Charging system Alternator 55A
- Battery Specifications V/Ah/CCA 12/70/300
OPERATION, PROTECTION AND INDICATION IN THE ELECTRICAL PANEL
- Protection against overcurrents Magneto-thermal switch
- Differential protection Electronic relay
- Emergency stop mushroom pushbutton included
- Group output control contactor Optional
TECHNICAL DATA OF THE ALTERNATOR
- Manufacturer MECCALTE
- Model ECP32-2S4C
- Frequency Hz 50
- Rated voltage V400
- Star-Series connection type
- Number of phases 3
- No. Poles 4
- Power ^T= 125 °C, 40ºC in CONTINUOUS kVA 45
- Power ^T= 163 °C, 27ºC in STANDBY kVA 49.5
- power factor 0.8
- Insulation class / ^Temp H/H
- Degree of protection IP23
- Short circuit current (for 20sec) 3 In
- Electronic voltage regulator -AVR
Note : Default alternator manufacturer and model. The manufacturer and model of the alternator may vary depending on availability, between Meccalte and Marelli, always with similar performance and characteristics.
LOGISTICS INFORMATION
- Weight approx. with liquids in radiator and sump kg 975
- Fuel volume in tank liters 117
